Create a VM Template with Proxmox Cloud-Init in No Time!

Are you tired of manually creating VMs in Proxmox every time you need a new Ubuntu server? I’ll show you how to create a Ubuntu 24.04 Cloud-Init template in Proxmox using a simple Makefile in this guide. This automation will save you valuable time and ensure consistency across your VM deployments.

Deep Dive into the Makefile

Let’s break down each component of our Makefile to understand exactly what’s happening at each step.

GIT: https://github.com/thiagousa/youtube/blob/main/31/Makefile

Variables Configuration

VM_ID=6000
VM_NAME=ubuntu-24-04-cloud-init-template
IMAGE_URL=https://cloud-images.ubuntu.com/noble/current/noble-server-cloudimg-amd64.img
IMAGE_NAME=noble-server-cloudimg-amd64.img
STORAGE=local
DISK_SIZE=50G
BRIDGE=vmbr0

• VM_ID: Unique identifier for your VM in Proxmox (must be unique across your cluster)
• VM_NAME: Descriptive name for your template
• IMAGE_URL: Direct link to Ubuntu’s cloud image
• IMAGE_NAME: Local filename for the downloaded image
• STORAGE: Proxmox storage location (default is ‘local’)
• DISK_SIZE: Final size of the VM disk after expansion
• BRIDGE: Network bridge for VM connectivity (default is vmbr0)

Step 0: Installing Required Tools

0_install_tools:
    apt install libguestfs-tools -y

This step installs libguestfs-tools, which provides essential utilities for manipulating disk images. The -y flag automatically accepts installation prompts.

Step 1: Preparing the Directory

1_prepare_dir:
    mkdir -p template

Creates a ‘template’ directory for our working files. The -p flag prevents errors if the directory already exists.

Step 2: Downloading the Cloud Image

2_download_image: 1_prepare_dir
    cd template && wget $(IMAGE_URL)

• Depends on 1_prepare_dir to ensure the directory exists
• Changes to the template directory
• Downloads the Ubuntu cloud image using wget
• Uses $(IMAGE_URL) variable for the download link

Step 3: Customizing the Image

3_customize_image: 2_download_image
    cd template && virt-customize --add $(IMAGE_NAME) --install qemu-guest-agent

• Depends on 2_download_image to ensure the image is available
• Uses virt-customize to modify the image
• Installs qemu-guest-agent for better VM management capabilities
• The --add flag specifies which image to modify

Step 4: Creating the VM

4_create_vm: 3_customize_image
    qm create $(VM_ID) --name $(VM_NAME) --numa 0 --ostype l26 --cpu cputype=host --cores 4 --sockets 2 --memory 6144 --net0 virtio,bridge=$(BRIDGE)

• Creates a new VM with specific hardware configurations:
• --numa 0: Disables NUMA (Non-Uniform Memory Access)
• --ostype l26: Specifies Linux 2.6/3.x/4.x kernel
• --cpu cputype=host: Uses host CPU type for best performance
• --cores 4: Allocates 4 CPU cores
• --sockets 2: Sets 2 CPU sockets
• --memory 6144: Allocates 6GB RAM
• --net0: Configures the first network interface with virtio driver

Step 5: Importing the Disk

5_import_disk: 4_create_vm
    cd template && qm importdisk $(VM_ID) $(IMAGE_NAME) $(STORAGE)

• Imports the customized cloud image as a disk for the VM
• Uses the specified storage location
• Creates a new disk with the VM ID

Step 6: Configuring the VM

6_configure_vm: 5_import_disk
    qm set $(VM_ID) --scsihw virtio-scsi-pci --scsi0 $(STORAGE):$(VM_ID)/vm-$(VM_ID)-disk-0.raw
    qm set $(VM_ID) --ide2 $(STORAGE):cloudinit
    qm set $(VM_ID) --boot c --bootdisk scsi0
    qm set $(VM_ID) --serial0 socket --vga serial0
    qm set $(VM_ID) --agent enabled=1

Multiple important configurations:

1. Sets up virtio-scsi-pci storage controller and attaches the imported disk
2. Configures Cloud-Init drive on IDE2
3. Sets boot order to use the SCSI disk
4. Configures serial console
5. Enables QEMU guest agent

Step 7: Resizing the Disk

7_resize_disk: 6_configure_vm
    qm disk resize $(VM_ID) scsi0 +$(DISK_SIZE)

• Expand the disk to the specified size (50G)
• Uses the + to indicate additional space rather than absolute size

Step 8: Creating the Template

8_create_template: 7_resize_disk
    qm template $(VM_ID)

• Converts the configured VM into a template
• After this step, the VM can’t be started but can be cloned

Step 9: Cleanup Option

9_clean:
    rm -rf template

• Optional cleanup step to remove the working directory
• Useful for saving space after template creation

Phony Targets

.PHONY: all 0_install_tools 1_prepare_dir 2_download_image 3_customize_image 4_create_vm 5_import_disk 6_configure_vm 7_resize_disk 8_exit_shell 9_create_template 10_clean

• Declares all targets as phony
• Ensures Make runs commands even if a file with the same name exists
• Prevents conflicts with actual files/directories

Template Usage Tips

After creating your template, you can clone it using:

qm clone <template_vm_id> <new_vm_id> --name <new_vm_name>

For Cloud-Init configuration, you can set parameters like:

qm set <new_vm_id> --ciuser your_username
qm set <new_vm_id> --cipassword your_password
qm set <new_vm_id> --ipconfig0 ip=dhcp

The process will execute all steps automatically, creating your template.

Creating VMs from the Template

To create a new VM from your template:

1. Go to your Proxmox web interface
2. Right-click the template
3. Select “Clone”
4. Choose “Linked Clone” for space efficiency or “Full Clone” for independent VMs
5. Configure Cloud-Init options (network, SSH keys, etc.)
6. Start your new VM

Benefits of Using This Approach

1. Consistency: Every VM created from this template will have the same base configuration
2. Speed: Create new VMs in seconds instead of minutes
3. Automation: Eliminate manual steps and reduce human error
4. Resource Efficiency: Linked clones save storage space
5. Maintainability: It is easy to update the template when needed

Conclusion

Using this automated approach with Make and Cloud-Init can streamline your VM creation process in Proxmox. The template system provides a solid foundation for deploying consistent, well-configured Ubuntu servers in your home lab or production environment.

Feel free to modify the Makefile variables to suit your needs, such as changing the VM ID, memory allocation, or disk size. Happy virtualization!
